Factor 55 FlatLink E (Expert)
A low-profile shackle/D-ring mount that folds neatly into the fairlead, the Factor 55 FlatLink E (Expert) delivers strength, versatility, and the benefits of Closed System Winching®.
The FlatLink E replaces conventional winch hooks with a safer, stronger, and more compact shackle mount design. Precision machined from billet aluminum and secured with an aerospace-grade titanium pin, this expert-level winching solution reduces the risk of failure while maximizing clearance and approach angle. EPDM rubber guards protect your fairlead from wear and rattling, while the large pear-shaped shackle mounting hole offers flexible rigging options for advanced operators. For recreational off-roaders, Factor 55 recommends the standard FlatLink for simpler, safer use. The FlatLink E is built for those who demand maximum versatility and performance under the harshest recovery conditions.
Closed System Winching® • Expert-Level Versatility • Military-Grade Durability
Key Features
- Replaces conventional winch hooks with a stronger shackle/D-ring mount
- Folds flat into the fairlead for a lower profile and better approach angles
- Large pear-shaped shackle mounting hole allows use with pin or bow ends
- Compatible with Closed System Winching® for maximum recovery safety
- EPDM rubber guards protect fairleads and eliminate rattling
- Installs in minutes with a titanium double-shear pin and snap ring
Specs
- Material: CNC machined 6000 series billet aluminum
- Finish: Military Specification Hard Anodized (Mil-A-8625 F Type III)
- Pin: 5/8” aerospace-grade 6AI-4V grade V titanium
- Compatible Line: Steel or synthetic ropes up to 3/8” diameter
- Compatible Shackles: Common ¾” shackles (pin and bow ends), soft shackles up to ¾”
- Load Capacity: 16,000 lbs (Ultimate Failure: >40,000 lbs)
- Thickness: Less than 1.75” folded flat
- Weight: 26 oz
- Compatible with roller fairlead license plate mounts
- Made in the USA
Watch It in Action
Why Buy from Expedition Superstore?
- Expert installation available — Schedule your build chat today!
- Authorized Factor 55 dealer with trusted off-road recovery expertise
- Fast, free shipping on most products
- One Stop Overland Shop — recovery, gear, and vehicle outfitting in one place
