Baja Designs LP6 Pro
A 6-inch powerhouse delivering 10,300 lumens with a 200° spread—engineered with cutting-edge cooling, replaceable optics, and Baja-proven durability.
Product Overview
The Baja Designs LP6 Pro is the ultimate blend of size, performance, and technology. Featuring a massive 10,300 lumens of total output, the LP6 uses Baja Designs’ patented Integrated Peripheral Technology (IPT) to project 8,600 lumens forward while dedicating 1,700 lumens to wide peripheral coverage. Its proprietary Direct Ducted Cooling (DDC) system channels air through the front housing over rear heat sinks, maximizing cooling efficiency and output. With an amber daytime running light, selectable low/high power modes, and multiple beam patterns, the LP6 Pro adapts to any trail or adventure. Built to endure extreme conditions, it exceeds military spec testing and carries Baja Designs’ limited lifetime warranty.
What’s Included
- One (1) Baja Designs LP6 Pro LED Light
- Mounting bracket and stainless steel hardware
- Installation instructions
Key Features
- Total Output: 10,300 lumens with a 200° spread of usable light.
- Integrated Peripheral Technology (IPT): 8,600 lumens forward projection + 1,700 lumens peripheral lighting.
- Direct Ducted Cooling: Innovative airflow system improves thermal efficiency and performance.
- Daytime Running Light: Amber DRL, plus selectable low and high power modes.
- uService® Technology: Replaceable lenses and optics without voiding warranty.
- MoistureBlock™ Sealing: Waterproof, rainproof, and submersible (IP69K rated).
- 5000K Daylight: Natural color temperature reduces driver fatigue.
- Built Tough: Hard-anodized aluminum housing, billet aluminum bezel, stainless steel bracket, and MIL-STD810G tested.
- Warranty: 30-day satisfaction guarantee and limited lifetime warranty.
Specs
- Forward Lumens: 8,600 (6 LEDs)
- Peripheral Lumens (IPT): 1,700 (4 LEDs)
- Total Lumens: 10,300
- Forward Wattage/Amps: 90W / 6.5A
- IPT Wattage/Amps: 15W / 1.0A
- Backlight: 4.14W / 0.3A
- Dimensions: 6.5" H × 6.5" W × 3.2" D
- Weight: 4.2 lbs
- Lens: Hardcoated polycarbonate
- Housing: Hard-anodized machined aluminum
- Connector: DT06-4S Deutsch
- LED Life Expectancy: 49,930 hours
- Protection: IP69K, IK10 compliant, built-in overvoltage protection
Beam Patterns
- Driving/Combo: Maximum trail coverage in one light, combining wide 42° and spot 6° optics for both near-field and distance lighting (Lighting Zone 3).
- High Speed Spot: Focused 6° long-range beam for distance illumination; designed to pair with Wide Driving or Driving/Combo lights (Lighting Zones 4 & 5).
Why Buy from Expedition Superstore?
- Race-Proven Lighting: Trusted by professionals at the Baja 1000 and beyond.
- Maximum Versatility: Multiple beam patterns, DRL, and high/low modes in one compact housing.
- One Stop Overland Shop: Lights, mounts, wiring, and accessories—all in one place.
