Diode Dynamics Heavy Duty Dual Output 4-pin Wiring Harness
Safely power your Diode Dynamics LED pods with backlight functionality using this heavy-duty, plug-and-play wiring harness.
Why Choose the Diode Dynamics Heavy Duty Wiring Harness?
Designed specifically for Stage Series pods with backlight features, this wiring harness delivers high-capacity performance with a clean, reliable install. Whether you’re using OEM aux switches or the included toggle switch, this harness gives you full control over both your backlight and main beam with easy-to-use connectors and a robust 14AWG wire build.
Product Overview
The Diode Dynamics 4-pin harness connects directly to your vehicle’s battery and uses a three-way switch to toggle between backlight, off, and full beam modes. It supports up to 25A of power, enough for most Diode Dynamics pod setups, and includes a 30A waterproof fuse and a 60A 12V relay to protect your electrical system.
Whether you're using C1, SSC2, SS3, or SS5 pods, this harness ensures safe and optimal operation. Built for rugged environments, the harness includes Deutsch DT connectors and an optional OEM aux switch adapter so you can integrate your lights directly with factory-installed switch panels when available.
Key Features
- Specifically built for Stage Series LED pods with backlight functionality
- High-capacity 14AWG wiring with 25A support
- Three-way toggle switch: Backlight / Off / Main Beam
- Deutsch DT connectors for secure plug-and-play setup
- Includes waterproof 30A fuse and 60A relay
- OEM aux switch adapter for factory switch integration
- Works with all popular Diode Dynamics pod types
Compatible Pod Draw (for Reference)
- C1 Sport: 1.2A | C1 Pro: 1.7A
- SSC2 Sport: 0.6A | SSC2 Pro: 1.75A
- SS3 Sport: 1.1A Main / 0.03A Backlight
- SS3 Pro: 2.7A Main / 0.03A Backlight
- SS3 Max: 3A Main / 0.03A Backlight
- SS5 Sport: 2.8A | SS5 Pro: 6.7A
What’s Included
- One (1) heavy-duty wiring harness
- One (1) three-way toggle switch
- One (1) OEM aux switch adapter
Installation
Whether you're wiring to a switch panel or using the toggle switch, our team can help you install this harness cleanly and safely. Get the most out of your lighting system by letting the experts handle the integration.
Schedule your build chat today!
Why Buy from Expedition Superstore?
- Authorized Diode Dynamics dealer
- All products backed by manufacturer warranty
- Expert product support for installs and troubleshooting
- Fast, secure shipping and 30-day returns
- Your One Stop Overland Shop
